Cisco Catalyst 2960-X Configuration Guide

Default SettingFeature
Enabled.
The switch might not support a pre-standard
powered device—such as Cisco IP phones
and access points that do not fully support
IEEE 802.3af—if that powered device is
connected to the switch through a crossover
cable. This is regardless of whether
auto-MIDX is enabled on the switch port.
Note
Auto-MDIX
Enabled (auto).Power over Ethernet (PoE)
Disabled on SFP module ports; enabled on all other
ports.
Keepalive messages
Interface Speed and Duplex Mode
Ethernet interfaces on the switch operate at 10, 100, 1000, or 10,000 Mb/s and in either full- or half-duplex
mode. In full-duplex mode, two stations can send and receive traffic at the same time. Normally, 10-Mb/s
ports operate in half-duplex mode, which means that stations can either receive or send traffic.
Switch models include Gigabit Ethernet (10/100/1000-Mb/s) ports, 10-Gigabit Ethernet ports, and small
form-factor pluggable (SFP) module slots supporting SFP modules.
Speed and Duplex Configuration Guidelines
When configuring an interface speed and duplex mode, note these guidelines:
•
The 10-Gigabit Ethernet ports do not support the speed and duplex features. These ports operate only
at 10,000 Mb/s and in full-duplex mode.
•
Gigabit Ethernet (10/100/1000-Mb/s) ports support all speed options and all duplex options (auto, half,
and full). However, Gigabit Ethernet ports operating at 1000 Mb/s do not support half-duplex mode.
•
For SFP module ports, the speed and duplex CLI options change depending on the SFP module type:
◦
The 1000BASE-x (where -x is -BX, -CWDM, -LX, -SX, and -ZX) SFP module ports support the
nonegotiate keyword in the speed interface configuration command. Duplex options are not
supported.
◦
The 1000BASE-T SFP module ports support the same speed and duplex options as the
10/100/1000-Mb/s ports.
For information about which SFP modules are supported on your switch, see the product release notes.
•
If both ends of the line support autonegotiation, we highly recommend the default setting of auto
negotiation.
•
If one interface supports autonegotiation and the other end does not, configure duplex and speed on both
interfaces; do not use the auto setting on the supported side.
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
22 OL-29420-01
Configuring Interface Characteristics
Interface Speed and Duplex Mode

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
