Cisco Catalyst 2960-X Configuration Guide

DETAILED STEPS
PurposeCommand or Action
Enter the configure terminal command at the privileged EXEC
prompt:
Step 1
Example:
Switch# configure terminal
Enter configuration commands, one per line. End with
CNTL/Z.
Switch(config)#
You do not need to add a space between the
interface type and the interface number. For
example, in the preceding line, you can specify
either gigabitethernet 1/0/1,
gigabitethernet1/0/1, gi 1/0/1, or gi1/0/1.
NoteEnter the interface global configuration command. Identify the
interface type, the switch number (only on stacking-capable
switches), and the number of the connector. In this example,
Gigabit Ethernet port 1 on switch 1 is selected:
Example:
Switch(config)# interface gigabitethernet1/0/1
Step 2
Switch(config-if)#
You can also configure a range of interfaces by using
the interface range or interface range macro global
Follow each interface command with the interface configuration
commands that the interface requires. The commands that you
Step 3
configuration commands. Interfaces configured in aenter define the protocols and applications that will run on the
range must be the same type and must be configured
with the same feature options.
interface. The commands are collected and applied to the interface
when you enter another interface command or enter end to return
to privileged EXEC mode.
Enter the show interfaces privileged EXEC command
to see a list of all interfaces on or configured for the
After you configure an interface, verify its status by using the
show privileged EXEC commands.
Step 4
switch. A report is provided for each interface that the
device supports or for the specified interface.
Example:
Adding a Description for an Interface
SUMMARY STEPS
1.
configure terminal
2.
interface interface-id
3.
description string
4.
end
5.
show interfaces interface-id description
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29420-01 25
Configuring Interface Characteristics
Adding a Description for an Interface

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
