Cisco Catalyst 2960-X Configuration Guide

•
IP address
•
802.1X username if applicable
•
Device category is specified as a wired station
•
State is specified as delete
•
Serial number, UDI
•
Time in seconds since the switch detected the disassociation
When the switch shuts down, it sends an attachment notification with the state delete and the IP address before
closing the NMSP connection to the MSE. The MSE interprets this notification as disassociation for all the
wired clients associated with the switch.
If you change a location address on the switch, the switch sends an NMSP location notification message that
identifies the affected ports and the changed address information.
Default LLDP Configuration
Table 8: Default LLDP Configuration
Default SettingFeature
DisabledLLDP global state
120 secondsLLDP holdtime (before discarding)
30 secondsLLDP timer (packet update frequency)
2 secondsLLDP reinitialization delay
Disabled to send and receive all TLVsLLDP tlv-select
DisabledLLDP interface state
DisabledLLDP receive
DisabledLLDP transmit
Disabled to send all LLDP-MED TLVs. When LLDP is globally
enabled, LLDP-MED-TLV is also enabled.
LLDP med-tlv-select
Configuration Guidelines
•
If the interface is configured as a tunnel port, LLDP is automatically disabled.
•
If you first configure a network-policy profile on an interface, you cannot apply the switchport voice
vlan command on the interface. If the switchport voice vlan vlan-id is already configured on an interface,
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29420-01 57
Configuring LLDP, LLDP-MED, and Wired Location Service
Default LLDP Configuration

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
