When STP is enabled and a port is reconfigured, the switch can take up to 30 seconds to check for loops.
The port LED is amber while STP reconfigures.
Changing the interface speed and duplex mode configuration might shut down and re-enable the interface
during the reconfiguration.
Caution
IEEE 802.3x Flow Control
Flow control enables connected Ethernet ports to control traffic rates during congestion by allowing congested
nodes to pause link operation at the other end. If one port experiences congestion and cannot receive any more
traffic, it notifies the other port by sending a pause frame to stop sending until the condition clears. Upon
receipt of a pause frame, the sending device stops sending any data packets, which prevents any loss of data
packets during the congestion period.
The switch ports can receive, but not send, pause frames.Note
You use the flowcontrol interface configuration command to set the interface’s ability to receive pause frames
to on, off, or desired. The default state is off.
When set to desired, an interface can operate with an attached device that is required to send flow-control
packets or with an attached device that is not required to but can send flow-control packets.
These rules apply to flow control settings on the device:
•
receive on (or desired): The port cannot send pause frames but can operate with an attached device that
is required to or can send pause frames; the port can receive pause frames.
•
receive off: Flow control does not operate in either direction. In case of congestion, no indication is
given to the link partner, and no pause frames are sent or received by either device.
For details on the command settings and the resulting flow control resolution on local and remote ports,
see the flowcontrol interface configuration command in the command reference for this release.
Note
Layer 3 Interfaces
The switch supports these types of Layer 3 interfaces:
•
SVIs: You should configure SVIs for any VLANs for which you want to route traffic. SVIs are created
when you enter a VLAN ID following the interface vlan global configuration command. To delete an
SVI, use the no interface vlan global configuration command. You cannot delete interface VLAN 1.
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29420-01 23
Configuring Interface Characteristics
IEEE 802.3x Flow Control

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
