Cisco Catalyst 2960-X Configuration Guide

Budgeting Power for Devices Connected to a PoE Port
When Cisco powered devices are connected to PoE ports, the switch uses Cisco Discovery Protocol (CDP)
to determine the CDP-specific power consumption of the devices, and the switch adjusts the power budget
accordingly. This does not apply to IEEE third-party powered devices. For these devices, when the switch
grants a power request, the switch adjusts the power budget according to the powered-device IEEE classification.
If the powered device is a class 0 (class status unknown) or a class 3, the switch budgets 15,400 mW for the
device, regardless of the CDP-specific amount of power needed. If the powered device reports a higher class
than its CDP-specific consumption or does not support power classification (defaults to class 0), the switch
can power fewer devices because it uses the IEEE class information to track the global power budget.
By using the power inline consumption wattage interface configuration command or the power inline
consumption default wattage global configuration command, you can override the default power requirement
specified by the IEEE classification. The difference between what is mandated by the IEEE classification and
what is actually needed by the device is reclaimed into the global power budget for use by additional devices.
You can then extend the switch power budget and use it more effectively.
You should carefully plan your switch power budget, enable the power monitoring feature, and make
certain not to oversubscribe the power supply.
Caution
When you manually configure the power budget, you must also consider the power loss over the cable
between the switch and the powered device.
Note
Budgeting Power to All PoE ports
Perform this task to configure the amount of power budgeted to a powered device connected to each PoE port
on a switch:
SUMMARY STEPS
1.
configure terminal
2.
no cdp run
3.
power inline consumption default wattage
4.
end
5.
show power inline consumption default
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
90 OL-29420-01
Configuring PoE
Budgeting Power for Devices Connected to a PoE Port

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
