Cisco Catalyst 2960-X Configuration Guide

SUMMARY STEPS
1.
configure terminal
2.
lldp holdtime seconds
3.
lldp reinit delay
4.
lldp timer rate
5.
lldp tlv-select
6.
interface interface-id
7.
lldp med-tlv-select
8.
end
9.
show lldp
10.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
(Optional) Specifies the amount of time a receiving device
should hold the information from your device before discarding
it.
lldp holdtime seconds
Example:
Switch(config)# lldp holdtime 120
Step 2
The range is 0 to 65535 seconds; the default is 120 seconds.
(Optional) Specifies the delay time in seconds for LLDP to
initialize on an interface.
lldp reinit delay
Example:
Switch(config)# lldp reinit 2
Step 3
The range is 2 to 5 seconds; the default is 2 seconds.
(Optional) Sets the sending frequency of LLDP updates in
seconds.
lldp timer rate
Example:
Switch(config)# lldp timer 30
Step 4
The range is 5 to 65534 seconds; the default is 30 seconds.
(Optional) Specifies the LLDP TLVs to send or receive.lldp tlv-select
Example:
Switch(config)# tlv-select
Step 5
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
60 OL-29420-01
Configuring LLDP, LLDP-MED, and Wired Location Service
Configuring LLDP Characteristics

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
