PurposeCommand or Action
Configures the policy attributes:
{voice | voice-signaling} vlan [vlan-id {cos
cvalue | dscp dvalue}] | [[dot1p {cos cvalue |
dscp dvalue}] | none | untagged]
Step 3
voiceSpecifies the voice application type.
Example:
Switch(config-network-policy)# voice vlan
voice-signalingSpecifies the voice-signaling application type.
vlanSpecifies the native VLAN for voice traffic.
vlan-id(Optional) Specifies the VLAN for voice traffic. The
range is 1 to 4094.
100 cos 4
cos cvalue(Optional) Specifies the Layer 2 priority class of
service (CoS) for the configured VLAN. The range is 0 to 7;
the default is 5.
dscp dvalue(Optional) Specifies the differentiated services
code point (DSCP) value for the configured VLAN. The range
is 0 to 63; the default is 46.
dot1p(Optional) Configures the telephone to use IEEE 802.1p
priority tagging and use VLAN 0 (the native VLAN).
none(Optional) Do not instruct the IP telephone about the
voice VLAN. The telephone uses the configuration from the
telephone key pad.
untagged(Optional) Configures the telephone to send
untagged voice traffic. This is the default for the telephone.
untagged(Optional) Configures the telephone to send
untagged voice traffic. This is the default for the telephone.
Returns to global configuration mode.exit
Example:
Switch(config)# exit
Step 4
Specifies the interface on which you are configuring a network-policy
profile, and enter interface configuration mode.
interface interface-id
Example:
Switch (config)# interface
Step 5
gigabitethernet2/0/1
Specifies the network-policy profile number.
network-policy profile number
Example:
Switch(config-if)# network-policy 1
Step 6
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
64 OL-29420-01
Configuring LLDP, LLDP-MED, and Wired Location Service
Configuring Network-Policy TLV
