Cisco Catalyst 2960-X Configuration Guide

SUMMARY STEPS
1.
configure terminal
2.
location {admin-tag string | civic-location identifier {id | host} | elin-location string identifier id |
custom-location identifier {id | host} | geo-location identifier {id | host}}
3.
exit
4.
interface interface-id
5.
location {additional-location-information word | civic-location-id {id | host} | elin-location-id id |
custom-location-id {id | host} | geo-location-id {id | host} }
6.
end
7.
Use one of the following:
•
show location admin-tag string
•
show location civic-location identifier id
•
show location elin-location identifier id
8.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Specifies the location information for an endpoint.
location {admin-tag string | civic-location identifier
{id | host} | elin-location string identifier id |
Step 2
• admin-tag—Specifies an administrative tag or site
information.
custom-location identifier {id | host} | geo-location
identifier {id | host}}
Example:
Switch(config)# location civic-location
identifier 1
• civic-location—Specifies civic location information.
• elin-location—Specifies emergency location information
(ELIN).
• custom-location—Specifies custom location information.
Switch(config-civic)# number 3550
Switch(config-civic)# primary-road-name "Cisco
Way"
Switch(config-civic)# city "San Jose"
Switch(config-civic)# state CA
Switch(config-civic)# building 19
Switch(config-civic)# room C6
Switch(config-civic)# county "Santa Clara"
Switch(config-civic)# country US
• geo-location—Specifies geo-spatial location information.
• identifier id—Specifies the ID for the civic, ELIN,
custom, or geo location.
• host—Specifies the host civic, custom, or geo location.
• string—Specifies the site or location information in
alphanumeric format.
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
66 OL-29420-01
Configuring LLDP, LLDP-MED, and Wired Location Service
Configuring Location TLV and Wired Location Service

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
