Cisco Catalyst 2960-X Configuration Guide

SUMMARY STEPS
1.
configure terminal
2.
system mtu bytes
3.
system mtu jumbo bytes
4.
system mtu routing bytes
5.
end
6.
copy running-config startup-config
7.
reload
8.
show system mtu
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
(Optional) Changes the MTU size for all Fast Ethernet interfaces on
the switch.
system mtu bytes
Example:
Switch(config)# system mtu 2500
Step 2
The range is 1500 to 1998 bytes; the default is 1500 bytes.
(Optional) Changes the MTU size for all Gigabit Ethernet and
10-Gigabit Ethernet interfaces on the switch or the switch stack.
system mtu jumbo bytes
Example:
Switch(config)# system mtu jumbo 7500
Step 3
The range is 1500 to 9198 bytes; the default is 1500 bytes.
(Optional) Changes the system MTU for routed ports. You can also
set the maximum MTU to be advertised by the routing protocols that
system mtu routing bytes
Example:
Switch(config)# system mtu routing 2000
Step 4
support the configured MTU size. The system routing MTU is the
maximum MTU for routed packets and is also the maximum MTU
that the switch advertises in routing updates for protocols such as
OSPF.
This command is not supported on switches running the
LAN base feature set.
Note
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 5
Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config
startup-config
Step 6
Catalyst 2960-XR Switch Interface and Hardware Component Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29420-01 75
Configuring System MTU
Configuring the System MTU

Cisco Catalyst 2960-X Specifications

General

Console port	RJ-45
USB 2.0 ports quantity	2
SFP module slots quantity	4
Installed SFP modules quantity	-
Gigabit Ethernet (copper) ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Power source	AC
Input current	5 A
AC input voltage	100 - 240 V
Power consumption (typical)	60.9 W
Number of power supply units	1
Redundant power supply (RPS) support	Yes
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	-5 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Switching protocols	UDP, TCP, RADIUS/TACACS+
Number of VLANs	1023
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Throughput	107.1 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
Number of static routes	1000
DHCP features	DHCP server
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SNMP, SSH
Access Control List (ACL) rules	3
Switch type	Managed
Switch layer	L2/L3
Safety	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1
Form factor	1U
Product color	Black
Total Power over Ethernet (PoE) budget	370 W
Power over Ethernet (PoE) ports quantity	24
Power over Ethernet plus (PoE+) ports quantity	12
Memory type	DRAM
Noise level	39 dB
Flash memory	128 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276870 h

Weight and Dimensions

Depth	368 mm
Width	445 mm
Height	45 mm
Weight	5800 g
