Catalyst 3550 Multilayer Switch Software Configuration Guide

78-11194-09

Chapter 1 Overview

Network Configuration Examples

Figure 1-1 Example Configurations

Catalyst 3550

GigaStack cluster

1-Gbps HSRP

50830

Catalyst 3550-12T

or Catalyst 3550-12G

switch

Gigabit

server

Catalyst 3550

switch

Cost-Effective Wiring Closet

High-Performance Workgroup

Redundant Gigabit Backbone

Catalyst

3550

cluster

Catalyst 3550 switchCatalyst 3550 switch
