Catalyst 3550 Multilayer Switch Software Configuration Guide

78-11194-09

Chapter 28 Configuring Network Security with ACLs

Configuring Named MAC Extended ACLs

This is a an example of a log for an extended IP ACL:

01:24:23:%SEC-6-IPACCESSLOGDP:list ext1 permitted icmp 10.1.1.15 -> 10.1.1.61 (0/0), 1

packet

01:25:14:%SEC-6-IPACCESSLOGDP:list ext1 permitted icmp 10.1.1.15 -> 10.1.1.61 (0/0), 7

packets

01:26:12:%SEC-6-IPACCESSLOGP:list ext1 denied udp 0.0.0.0(0) -> 255.255.255.255(0), 1

packet

01:31:33:%SEC-6-IPACCESSLOGP:list ext1 denied udp 0.0.0.0(0) -> 255.255.255.255(0), 8

packets

Note that all logging entries for IP ACLs start with %SEC-6-IPACCESSLOG with minor variations in format

depending on the kind of ACL and the access entry that has been matched.

This is an example of an output message when the log-input keyword is entered:

00:04:21:%SEC-6-IPACCESSLOGDP:list inputlog permitted icmp 10.1.1.10 (Vlan1

0001.42ef.a400) -> 10.1.1.61 (0/0), 1 packet

A log message for the same sort of packet using the log keyword does not include the input interface

information:

00:05:47:%SEC-6-IPACCESSLOGDP:list inputlog permitted icmp 10.1.1.10 -> 10.1.1.61 (0/0), 1

packet

Configuring Named MAC Extended ACLs

You can filter non-IP traffic on a VLAN and on a physical Layer 2 interface by using MAC addresses

and named MAC extended ACLs. The procedure is similar to that of configuring other extended named

ACLs. You can use a number to name the access list, but MAC access list numbers from 700 to 799 are

not supported.

Note Named MAC extended ACLs cannot be applied to Layer 3 interfaces.

For more information about the supported non-IP protocols in the mac access-list extended command,

refer to the command reference for this release.

Note Though visible in the command-line help strings, appletalk is not supported as a matching condition for

the deny and permit MAC access-list configuration mode commands nor is matching on the EtherType

of any SNAP-encapsulated packet with a nonzero Organizational Unique Identifier (OUI).

Beginning in privileged EXEC mode, follow these steps to create a named MAC extended ACL:

Command Purpose

Step 1

configure terminal Enter global configuration mode.

Step 2

mac access-list extended name Define an extended MAC access list using a name.
