Chapter 31 Configuring IP Unicast Routing
Configuring BGP
Based on the community, you can control which routing information to accept, prefer, or distribute to
other neighbors. A BGP speaker can set, append, or modify the community of a route when learning,
advertising, or redistributing routes. When routes are aggregated, the resulting aggregate has a
COMMUNITIES attribute that contains all communities from all the initial routes.
You can use community lists to create groups of communities to use in a match clause of a route map.
As with an access list, a series of community lists can be created. Statements are checked until a match
is found. As soon as one statement is satisfied, the test is concluded.
To set the COMMUNITIES attribute and match clauses based on communities, see the match
community-list and set community route-map configuration commands in the “Using Route Maps to
Redistribute Routing Information” section on page 31-79.
By default, no COMMUNITIES attribute is sent to a neighbor. You can specify that the COMMUNITIES
attribute be sent to the neighbor at an IP address by using the neighbor send-community router
configuration command.
Beginning in privileged EXEC mode, follow these steps to create and to apply a community list:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip community-list community-list-number
{permit | deny} community-number
Create a community list and assign it a number.
• The community-list-number is an integer from 1 to 99 that
identifies one or more permit or deny groups of communities.
• The community-number is the number configured by a set
community route-map configuration command.
Step 3
router bgp autonomous-system Enter BGP router configuration mode.
Step 4
neighbor {ip-address | peer-group name}
send-community
Specify that the COMMUNITIES attribute be sent to the neighbor at
this IP address.
Step 5
set comm-list list-num delete (Optional) Remove communities from the community attribute of an
inbound or outbound update that match a standard or extended
community list specified by a route map.
Step 6
exit Return to global configuration mode.
Step 7
ip bgp-community new-format (Optional) Display and parse BGP communities in the format AA:NN.
A BGP community appears in a 2-part format two bytes long. The Cisco
default community format is in the format NNAA. In the most recent
RFC for BGP, a community takes the form AA:NN, where the first part
is the AS number and the second part is a 2-byte number.
Step 8
end Return to privileged EXEC mode.
Step 9
show ip bgp community Verify the configuration.
Step 10
copy running-config startup-config (Optional) Save your entries in the configuration file.
