Single Access Switch
(Redundant Port Channel
Uplink)
Single Access Switch
(Single Port Channel
Uplink)
Single Access Switch
(Single Uplink)
Setting
Version 2Version 2Version 2SSH
EnabledEnabledEnabledSCP
EnabledEnabledEnabledVTY Access to Switch
EnabledEnabledEnabledService Timestamp
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
The following VLANs are
created:
• Default VLAN
• Data VLAN
• Voice VLAN
• Management VLAN
VLAN
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Layer 3 settings
configured on the
management port, based
on Quick Setup
Management Interface
IPv6 host policy createdIPv6 host policy createdIPv6 host policy createdIPv6 Host Policy
Auto QoS Policy for
Access defined
Auto QoS Policy for
Access defined
Auto QoS Policy for
Access defined
QoS Policy for Downlink
Ports
QoS Policy for
Distribution created
QoS Policy for
Distribution created
QoS Policy for
Distribution created
QoS Policy for Uplink
Ports
Selected ports configured
as Port-channel in trunk
mode, set to allow all
VLANs.
Selected ports configured
as Port-channel in trunk
mode, set to allow all
VLANs.
Selected uplink interfaces
configured as trunk ports,
set to allow all VLANs
Uplink Interfaces
Downlink ports
configured in Access
mode
Downlink ports
configured in Access
mode
Downlink ports
configured in Access
mode
Downlink Interfaces
Port-channel to
distribution created
Port-channel to
distribution created
Not configuredPort-channel
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-0594
Configuring the Switch
Configuring Your Device Based on a Site Profile
