Cisco Catalyst C3850 Series User Manual

CONTENTS
Preface xi
PREFACE
Document Conventions xi
Related Documentation xiii
Obtaining Documentation and Submitting a Service Request xiii
Product Overview 1
CHAPTER 1
Switch Models 1
Front Panel 6
10/100/1000 Ports 8
PoE, PoE+, and Cisco UPoE Ports 8
SFP and QSFP Module Slots 9
Management Ports 9
USB Type A Port 10
Network Modules 11
SFP and SFP+ Modules 13
LEDs 13
SYST LED 16
XPS LED 16
Port LEDs and Modes 17
USB Console LED 19
S-PWR LED 19
ACTV LED 20
STACK LED 20
PoE LED 21
UID/Beacon LED 21
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-05ii
Contents

Cisco Catalyst C3850 Series Specifications

General

Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
RAM	4 GB
Flash Memory	4 GB
Series	Catalyst 3850
Power Supply Options	AC or DC
Software	Cisco IOS XE
Operating Temperature	32 to 113°F (0 to 45°C)
Ports	12, 24, or 48 x 10/100/1000 Ethernet ports
Uplink Interfaces	Optional 10G uplinks
