Cisco Catalyst C3850 Series User Manual

DescriptionNetwork Module
13
This module has four slots:
Two slots (left side) support only 1 G SFP modules and two slots (right side)
support either 1 G SFP or 10 G SFP modules.
This is supported on the following switch models:
Note
• WS-C3850-24T/P/U
• WS-C3850-48T/F/P/U
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-12S
• WS-C3850-24S
C3850-NM-2-10G
This module has four 10 G slots or four 1 G slots.
This is supported on the following switch models:
Note
• WS-C3850-48T/F/P/U
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-12XS
• WS-C3850-24XS
C3850-NM-4-10G
This module has eight 10 G slots with an SFP+ port in each slot. Each port supports
a 1 G or 10 G connection
This is supported on the following switch models:
Note
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-24XS
C3850-NM-8-10G
This module has two 40 G slots with a QSFP+ connector in each slot.
This is supported on the following switch models:
Note
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-24XS
C3850-NM-2-40G
Insert this blank module when the switch has no uplink ports (this is required for
sufficient air flow).
C3850-NM-BLANK
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-0554
Installing a Network Module
Network Module Overview

Cisco Catalyst C3850 Series Specifications

General

Max Stacking Units	9
Layer Support	Layer 2 and Layer 3
RAM	4 GB
Flash Memory	4 GB
Series	Catalyst 3850
Power Supply Options	AC or DC
Software	Cisco IOS XE
Operating Temperature	32 to 113°F (0 to 45°C)
Ports	12, 24, or 48 x 10/100/1000 Ethernet ports
Uplink Interfaces	Optional 10G uplinks
