Cisco Catalyst C9200-48T User Manual

Full PoE with Redundant
Power Supply
Available PoEDefault Power SupplyModels
740W370WPWR-C5-600WACC9200L-24P-4X
740W370WPWR-C5-600WACC9200L-24PXG-2Y
740W370WPWR-C5-600WACC9200L-24PXG-4X
——PWR-C5-125WACC9200L-24T-4G
——PWR-C5-125WACC9200L-24T-4X
1440W740WPWR-C5-1KWACC9200L-48P-4G
1440W740WPWR-C5-1KWACC9200L-48P-4X
740W370WPWR-C5-600WACC9200L-48PL-4G
740W370WPWR-C5-600WACC9200L-48PL-4X
1440W740WPWR-C5-1KWACC9200L-48PXG-2Y
1440W740WPWR-C5-1KWACC9200L-48PXG-4X
——PWR-C5-125WACC9200L-48T-4G
——PWR-C5-125WACC9200L-48T-4X
The power supply modules have two status LEDs.
Table 5: Switch Power Supply Module LEDs
DescriptionPS OKDescriptionAC OK
Output is disabled, or input is outside
operating range (AC LED is off).
OffNo AC input power.Off
Power output to switch active.GreenAC input power present.Green
Output has failed.Red
Fan Modules
The Cisco Catalyst 9200 Series Switches supports two internal fixed 12-V fan modules and two field-replaceable
fan modules (C9200-FAN=). The C9200 models support modular fans whereas the C9200L models provide
two internal fixed fans.
For information about the type of fan module supported on different switch models, see Switch Models, on
page 1.
The air circulation system consists of the fan modules and the power supply modules. The airflow patterns
vary depending on the power supply configuration. The switch can operate at ambient temperature if one of
the fans fail.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
11
Product Overview
Fan Modules

Cisco Catalyst C9200-48T Specifications

General

Total 10/100/1000 or Multigigabit copper ports	48 x 10/100/1000
Switching Capacity	176 Gbps
DRAM	4 GB
Flash	16 GB
PoE Support	No
MTBF	1, 000, 000 hours
Power Device	Internal power supply
Rack Mountable	Yes
Product Type	Layer 3 Switch
Uplink Ports	4 x 10 Gigabit Ethernet
Input Voltage	AC 120/230 V
Authentication Method	Secure Shell (SSH), RADIUS, TACACS+
Operating Temperature	0 to 45°C
