CHAPTER 1
Product Overview
• Switch Models, on page 1
• Front Panel Components, on page 3
• Rear Panel, on page 8
• Network Configurations, on page 13
Switch Models
The Cisco Catalyst 9200 Series switches have four modular (C9200) and eight fixed (C9200L) switch models.
The following tables describe all the available Cisco Catalyst 9200 Series switches and the features supported.
Table 1: C9200L Switch Models and Descriptions
DescriptionSwitch Model
Stackable 24x1G PoE+ ports; 4x1G SFP fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-24P-4G
Stackable 24x1G PoE+ ports; 4x10G SFP+ fixed uplink ports; 2
power supply slots; 2 fixed fans; supports StackWise-80.
C9200L-24P-4X
Stackable 24x1G ports; 4x1G SFP fixed uplink ports; 2 power supply
slots; 2 fixed fans; supports StackWise-80.
C9200L-24T-4G
Stackable 24x1G ports; 4x10G SFP+ fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-24T-4X
Stackable 48x1G PoE+ ports; 4x1G SFP fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-48P-4G
Stackable 48x1G PoE+ ports; 4x10G SFP+ fixed uplink ports; 2
power supply slots; 2 fixed fans; supports StackWise-80.
C9200L-48P-4X
Stackable 48x1G ports; 4x1G SFP fixed uplink ports; 2 power supply
slots; 2 fixed fans; supports StackWise-80.
C9200L-48T-4G
Stackable 48x1G ports; 4x10G SFP+ fixed uplink ports; 2 power
supply slots; 2 fixed fans; supports StackWise-80.
C9200L-48T-4X
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
1
