APPENDIX B
Switch LEDs
LEDs, on page 79
Console LED, on page 79
System LED, on page 80
MASTER LED, on page 80
STACK LED, on page 81
PoE LED, on page 82
Port LEDs and Modes, on page 82
Beacon LED, on page 84
RJ-45 Console Port LED, on page 85
Fan LED, on page 85
Uplink Port LEDs, on page 85
LEDs
You can use the switch LEDs to monitor switch activity and its performance.
Figure 51: Switch Front Panel LEDs
Console LED
The console LED indicates whether the USB console port or the bluetooth console is enabled.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
79
