Figure 21: Connecting the StackWise Cable in a StackWise Port
StackWise cable2Connector screws1
c) Finger-tighten the screws in clockwise direction.
Step 5 Connect the other end of the cable to the port on the other switch and finger-tighten the screws. Avoid
over-tightening the screws.
Removing and installing the StackWise cable can shorten its useful life. Do not remove and insert
the cable more often than is absolutely necessary (installing and removing it up to 200 times is
supported).
Caution
When you need to remove the StackWise cable from the connector, make sure to fully unscrew the correct
screws. When the connectors are not being used, replace the dust covers.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
30
Installing the Switch
Connecting to the StackWise Ports

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco Catalyst C9200-48T and is the answer not in the manual?

Cisco Catalyst C9200-48T Specifications

General IconGeneral
Total 10/100/1000 or Multigigabit copper ports48 x 10/100/1000
Switching Capacity176 Gbps
DRAM4 GB
Flash16 GB
PoE SupportNo
MTBF1, 000, 000 hours
Power DeviceInternal power supply
Rack MountableYes
Product TypeLayer 3 Switch
Uplink Ports4 x 10 Gigabit Ethernet
Input VoltageAC 120/230 V
Authentication MethodSecure Shell (SSH), RADIUS, TACACS+
Operating Temperature0 to 45°C
