Cisco Catalyst C9200-48T User Manual

Figure 31: AC-Power Supply with Power Cord Retainer
Retainer clamp4Power cord1
The strap end that is fixed
to the power supply
module
5Tabs on the retainer clamp2
--Power cord retainer strip3
a) Fix the strap in the power cord retainer to the power supply module, to hold the clamp in place.
b) Slide the retainer clamp around the AC power cord and position the retainer closest to the power supply.
Depending on the width of the power cord, adjust the size of the retainer clamp, if required.
Note
c) Press the tabs on the retainer clamp towards each other to secure the AC power cord.
Step 7 Connect the power cord to the power supply and to an AC power outlet. Turn on the power at the power
source.
Step 8 Confirm that the power supply AC OK and PS OK LED are green.
Cisco Catalyst 9200 Series Switches Hardware Installation Guide
47
Installing a Power Supply Unit
Installing or Replacing an AC Power Supply Module

Cisco Catalyst C9200-48T Specifications

General

Total 10/100/1000 or Multigigabit copper ports	48 x 10/100/1000
Switching Capacity	176 Gbps
DRAM	4 GB
Flash	16 GB
PoE Support	No
MTBF	1, 000, 000 hours
Power Device	Internal power supply
Rack Mountable	Yes
Product Type	Layer 3 Switch
Uplink Ports	4 x 10 Gigabit Ethernet
Input Voltage	AC 120/230 V
Authentication Method	Secure Shell (SSH), RADIUS, TACACS+
Operating Temperature	0 to 45°C
