Cisco Catalyst IE-9320-26S2C-A User Manual

Front Panel
All the ports and LEDs of Cisco Catalyst IE9300 Rugged Series Switches are on the front panel. This section
shows the arrangement of features on the front panel; see other sections for detailed information about ports
and LEDs.
• LEDs are distributed over the front panel, each one near the interface it relates to. System status
LEDs that are not associated with a specific interface are on the left side of the front panel.
• The front panels of IE9310 and IE9320 models are nearly identical. Later sections note the few
differences.
• The power supply LEDs are visible on the rear of the switch, where the units are installed.
Note
Figure 1: Cisco Catalyst IE9300 Rugged Series Switch Front Panel
Alarms6Display mode button1
RJ-45 console port7Express Setup button2
Cisco Catalyst IE9300 Rugged Series Switch Hardware Installation Guide
3
Cisco IE9300 Rugged Series Overview
Front Panel

Cisco Catalyst IE-9320-26S2C-A Specifications
