• Ring terminal (such as Tyco part number 2-34158-1 for 16-14 AWG or 2-34852-1 for 12-10 AWG
wire)
• Spade terminal (such as Tyco part number 54367-2 for 16-14 AWG wire)
• Flanged spade terminal (such as Tyco part number 2-324165-1 for 16-14 AWG wire or 1-324581-1
for 12-10 AWG wire)
• Use the 16-14 AWG wire and appropriate terminals for the AC or high-voltage DC power supply
• Use the12-10 AWG wire and appropriate terminals for the low-voltage DC power supply.
• Crimping tool (such as Thomas & Bett part number WT2000, ERG-2001)
• 6-gauge copper ground wire
• 12-AWG wire (minimum) for the low-voltage power-supply module and 16-AWG (minimum) wire for
the high-voltage power-supply module
• For power source connections, use wires rated for at least 194°F (90°C).
• UL- and CSA-rated style 1007 or 1569 twisted-pair copper wire
• Wire-stripping tools for stripping 6-, 10-, 12-, 14-, and 16-gauge wires
• Number-2 Phillips screwdriver
• Flat-blade screwdriver
• Ratcheting torque screwdriver with a number-2 and a number-1 Phillips head that exerts up to 15
pound-force inches (lbf-in.) or 240 ounce-force inches (ozf-in.) of pressure
• Panduit crimping tool with optional controlled-cycle mechanism (model CT-720, CT-920, CT-920CH,
CT-930, or CT-940CH)
• Wire-stripping tools
• 12-gauge copper ground wire (insulated or noninsulated) when using the single-ground connection
• 6-gauge copper ground wire (insulated or noninsulated) when using the dual-ground connection
• The supplied dual-hole lug from the accessory kit for the dual ground connection
• Four leads of 16-gauge copper wire
Ground the Switch
Follow the grounding procedures at your site and observe the following warnings:
This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority
or an electrician if you are uncertain that suitable grounding is available. Statement 1024
Warning
Cisco Catalyst IE9300 Rugged Series Switch Hardware Installation Guide
40
Power Supply Installation
Ground the Switch
