Figure 12: Attaching Brackets (RM-RGD-ETSI=) for ETSI Racks
Power-supply-side mounting position3Phillips flat-head screws1
Cable-side mounting position2
What to do next
Complete the steps in the section Rack-Mount the Switch, on page 22.
Rack-Mount the Switch
After you attach the brackets on the switch, attach the brackets to the rack, using the following illustrations
and steps. The illustration displays, from top to bottom, midrack mounting, front mounting, and rear mounting.
Cisco Catalyst IE9300 Rugged Series Switch Hardware Installation Guide
22
Switch Installation
Rack-Mount the Switch
