Console Port Adapter Pinouts
The console port uses an 8-pin RJ-45 connector. If you did not order a console cable, you must provide an
RJ-45-to-DB-9 adapter cable to connect the switch console port to a PC console port. You must provide an
RJ-45-to-DB-25 female DTE adapter if you want to connect the switch console port to a terminal. You can
order an adapter (part number ACS-DSBUASYN=).
The following table lists the pinouts for the console port, the RJ-45-to-DB-9 adapter cable, and the console
device.
Table 16: Console Port Adapter Pinouts (RJ-45-to-DB-9)
Console Device
Signal
RJ-45-to- DB-9 Terminal Adapter
DB-9 Pin
Switch Console Port (DTE)
Signal
CTS8RTS
DSR6DTR
RxD2TxD
GND5GND
TxD3RxD
DTR4DSR
RTS7CTS
The RJ-45-to-DB-25 female DTE adapter is not supplied with the switch. You can order this adapter
from Cisco (part number ACS-DSBUASYN=).
Note
The following table lists the pinouts.
Table 17: Console Port Adapter Pinouts (RJ-45-to-DB-25)
Console Device
Signal
RJ-45-to-DB-25 Adapter
DB-25 Pin
Switch Console Port (DTE)
Signal
CTS5RTS
DSR3DTR
RxD6TxD
GND7GND
TxD2RxD
DTR20DSR
RTS4CTS
Cisco Catalyst IE9300 Rugged Series Switch Hardware Installation Guide
72
Cables and Connectors
Console Port Adapter Pinouts
