Page #148 background image
14-8
Cisco 850 Series and Cisco 870 Series Access Routers Software Configuration Guide
OL-5332-01
Chapter 14 Troubleshooting
ATM Troubleshooting Commands
00:03:00: DSL: 1: Modem state = 0x8
00:03:00: DSL: 1: Modem state = 0x8
00:03:00: DSL: 1: Modem state = 0x8
00:03:00: DSL: 1: Modem state = 0x8
debug atm packet Command
Use the debug atm packet command to display all process-level ATM packets for both outbound and
inbound packets. The output reports information online when a packet is received or a transmission is
attempted. The no form of this command disables debugging output.
Caution Because the debug atm packet command generates a significant amount of output for every packet
processed, use it only when network traffic is low, so that other system activities are not adversely
affected.
The command syntax is:
debug atm packet [interface atm number [vcd vcd-number][vc vpi/vci number]]
no debug atm packet [interface atm number [vcd vcd-number][vc vpi/vci number]]
where the keywords are defined as follows:
interface atm number (Optional) ATM interface or subinterface number.
vcd vcd-number (Optional) Number of the virtual circuit designator (VCD).
vc vpi/vci number VPI/VCI value of the ATM PVC.
Example 14-7 shows sample output for the debug atm packet command.
Example 14-7 Viewing ATM Packet Processing
Router# debug atm packet
Router#
01:23:48:ATM0(O):
VCD:0x1 VPI:0x1 VCI:0x64 DM:0x0 SAP:AAAA CTL:03 OUI:000000 TYPE:0800 Length:0x70
01:23:48:4500 0064 0008 0000 FF01 9F80 0E00 0010 0E00 0001 0800 A103 0AF3 17F7 0000
01:23:48:0000 004C BA10 ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD
01:23:48:ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD
01:23:48:ABCD ABCD ABCD ABCD ABCD
01:23:48:
01:23:48:ATM0(I):
VCD:0x1 VPI:0x1 VCI:0x64 Type:0x0 SAP:AAAA CTL:03 OUI:000000 TYPE:0800 Length:0x70
01:23:48:4500 0064 0008 0000 FE01 A080 0E00 0001 0E00 0010 0000 A903 0AF3 17F7 0000
01:23:48:0000 004C BA10 ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD
01:23:48:ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD ABCD
01:23:48:ABCD ABCD ABCD ABCD ABCD
01:23:48:
Table 14-3 describes some of the fields shown in the debug atm packet command output.
Ta b l e 14-3 debug atm packet Command Output Description
Field Description
ATM 0 Interface that is generating the packet.
(O) Output packet. (I) would mean receive packet.
