Cisco CISCO851-K9 - 851 Integrated Services Router User Manual

4-11
Cisco 850 Series and Cisco 870 Series Access Routers Software Configuration Guide
OL-5332-01
Chapter 4 Configuring PPP over ATM with NAT
Configuration Example
Note If you want to use NAT with a virtual-template interface, you must configure a loopback interface. See
Chapter 1, “Basic Router Configuration,” for information on configuring the loopback interface.
For complete information on NAT commands, see the Cisco IOS Release 12.3 documentation set. For
more general information on NAT concepts, see
Appendix B, “Concepts.”
Configuration Example
The following configuration example shows a portion of the configuration file for a client in the PPPoA
scenario described in this chapter.
The VLAN interface has an IP address of 192.168.1.1 with a subnet mask of 255.255.255.0. NAT is
configured for inside and outside.
Note Commands marked by “(default)” are generated automatically when you run the show running-config
command.
!
interface Vlan1
ip address 192.168.1.1 255.255.255.0
ip nat inside
ip virtual-reassembly (default)
!
interface ATM0
no ip address
ip nat outside
ip virtual-reassembly
no atm ilmi-keepalive
pvc 8/35
encapsulation aal5mux ppp dialer
dialer pool-member 1
!
dsl operating-mode auto
!
Step 10
exit
Example:
Router(config-if)# exit
Router(config)#
Exits configuration mode for the ATM interface.
Step 11
access-list access-list-number {deny | permit}
source [source-wildcard]
Example:
Router(config)# access-list 1 permit
192.168.1.0 255.255.255.0
Defines a standard access list permitting addresses
that need translation.
Note All other addresses are implicitly denied.
Command Purpose
