Cisco 850 Series and Cisco 870 Series Access Routers Software Configuration Guide
OL-5332-01
Chapter 4 Configuring PPP over ATM with NAT
Configure DSL Signaling Protocol
Note If you are integrating your Cisco router into a European network, use the dsl dsl-mode shdsl symmetric
annex {A | B} command to choose annex B. The router uses annex A by default (United States).
Verify the Configuration
You can verify that the configuration is set the way you want by using the show controllers dsl command
from the privileged EXEC mode.
Router# show controllers dsl 0
DSL 0 controller UP
SLOT 0: Globespan xDSL controller chipset
DSL mode: SHDSL Annex A
Frame mode: Utopia
Configured Line rate: Auto
Line Re-activated 6 times after system bootup
LOSW Defect alarm: ACTIVE
CRC per second alarm: ACTIVE
Line termination: CPE
Current 15 min CRC: 0
Current 15 min LOSW Defect: 0
Current 15 min ES Defect: 0
Current 15 min SES Defect: 0
Current 15 min UAS Defect: 33287
Previous 15 min CRC Defect: 0
Previous 15 min LOSW Defect: 0
Previous 15 min ES Defect: 0
Previous 15 min SES Defect: 0
Previous 15 min UAS Defect: 0
Line-0 status
Chipset Version: 0
Firmware Version: A388
Modem Status: Data, Status 1
Last Fail Mode: No Failure status:0x0
Line rate: 2312 Kbps
Framer Sync Status: In Sync
Rcv Clock Status: In the Range
Loop Attenuation: 341.1450 dB
Transmit Power: 7.5 dB
Step 6
ignore-error-duration number
Example:
Router(config-controller)#
ignore-error-duration 15
Router(config-controller)#
Specifies how long, 15 to 30 seconds, to ignore
errors.
Step 7
exit
Example:
Router(config-controller)# exit
Router(config)#
Exits controller configuration mode, returning to
global configuration mode.
