C-7
Cisco 850 Series and Cisco 870 Series Access Routers Software Configuration Guide
OL-5332-01
Appendix C ROM Monitor
Console Download
The following display shows an example of entering the confreg command:
rommon 7> confreg
Configuration Summary
enabled are:
console baud: 9600
boot: the ROM Monitor
do you wish to change the configuration? y/n [n]: y
enable “diagnostic mode”? y/n [n]: y
enable “use net in IP bcast address”? y/n [n]:
enable “load rom after netboot fails”? y/n [n]:
enable “use all zero broadcast”? y/n [n]:
enable “break/abort has effect”? y/n [n]:
enable “ignore system config info”? y/n [n]:
change console baud rate? y/n [n]: y
enter rate: 0 = 9600, 1 = 4800, 2 = 1200, 3 = 2400 [0]: 0
change the boot characteristics? y/n [n]: y
enter to boot:
0 = ROM Monitor
1 = the boot helper image
2-15 = boot system
[0]: 0
Configuration Summary
enabled are:
diagnostic mode
console baud: 9600
boot: the ROM Monitor
do you wish to change the configuration? y/n [n]:
You must reset or power cycle for new config to take effect
Console Download
You can use console download, a ROM monitor function, to download either a software image or a
configuration file over the router console port. After download, the file is either saved to the mini-flash
memory module or to main memory for execution (image files only).
Use console download when you do not have access to a TFTP server.
Note If you want to download a software image or a configuration file to the router over the console port, you
must use the ROM monitor dnld command.
Note If you are using a PC to download a Cisco IOS image over the router console port at 115,200 bps, ensure
that the PC serial port is using a 16550
universal asynchronous transmitter/receiver (UART). If the PC
serial port is not using a 16550
UART, we recommend using a speed of 38,400 bps or less when
downloading a Cisco IOS image over the console port.
