Cisco CRS Series - Configuring MVPN MLDP BIDIR

PurposeCommand or Action
Enters interface configuration mode to define the
IPv4 address for the interface.
interface type interface-path-id
Example:
RP/0/RP0/CPU0:router(config-ospf-ar)# interface
Step 9
Similarly, configure multiple interfaces for
a multicast configuration.
Note
Bundler-Ether1
Enters multicast routing configuration mode.multicast-routing [address-family {ipv4 | ipv6}]
Example:
RP/0/RP0/CPU0:router(config)# multicast-routing
Step 10
address-family ipv4
RP/0/RP0/CPU0:router(config)# multicast-routing
address-family ipv6
Configures global multicast Cisco Non Stop
Forwarding.
nsf
Example:
RP/0/RP0/CPU0:router(config-mcast-default-ipv4)#
Step 11
nsf
Enables or disabled per (S, G) rate calculation.rate-per-route
Example:
RP/0/RP0/CPU0:router(config-mcast-default-ipv4)#
Step 12
rate-per-route
Enables IP multicast for interfaces.interface all enable
Example:
RP/0/RP0/CPU0:router(config-mcast-default-ipv4)#
Step 13
interface all enable
Enters PIM configuration mode, or PIM
address-family configuration submode.
router pim [address-family {ipv4 | ipv6}]
Example:
RP/0/RP0/CPU0:router(config)# router pim
Step 14
address-family ipv4
Configures the Rendezvous point and assigns an RP
to multicast groups.
rp-address ip-address [group-access-list] [bidir]
Example:
RP/0/RP0/CPU0:router(config-pim-default-ipv4)#
Step 15
The RP mechanism can be static, auto-rp, or
BSR.
Note
rp-address 172.16.6.22 group_1 bidir
•
If you specify a group-access-list-number
value, you must configure that access list using
the ipv4 access-list command.
Cisco IOS XR Multicast Configuration Guide for the Cisco CRS Router, Release 5.2.x
73
Implementing Multicast Routing on Cisco IOS XR Software
Configuring Native PIM BIDIR
