PurposeCommand or Action
Configures the partitioned mdt mldp.mdt partitioned mldp {ipv4 | ipv6} mp2mp bidir
Example:
RP/0/RP0/CPU0:router(config-bgp)# mdt partitioned mldp
Step 31
ipv4 mp2mp bidir
Enables IP multicast for interfaces.interface all enable
Example:
RP/0/RP0/CPU0:router(config-mcast-default-ipv4)#
Step 32
interface all enable
Enters interface configuration mode to define the
IPv4 address for the interface.
interface type interface-path-id
Example:
RP/0/RP0/CPU0:router(config)# interface loopback 7
Step 33
Enters interface configuration mode to define the
IPv4 address for the interface.
description line
Example:
RP/0/RP0/CPU0:router(config-if)# description "loopback
Step 34
interface for MLDP vrf on PE1"
Sets VRF in which the interface operates.
vrf vrf_name
Example:
RP/0/RP0/CPU0:router(config-if)# vrf A1_MSPMSI
Step 35
(Optional) Defines the IPv4 address for the
interface.
{ipv4 | ipv6} address address mask
Example:
RP/0/RP0/CPU0:router(config-if)# ipv4 address
Step 36
107.107.107.107 255.255.255.255
RP/0/RP0/CPU0:router(config-if)# ipv6 address
107:107::107:107/128
Enters PIM configuration mode, or PIM
address-family configuration submode.
router pim [address-family {ipv4 | ipv6}]
Example:
RP/0/RP0/CPU0:router(config)# router pim address-family
Step 37
ipv4
Cisco IOS XR Multicast Configuration Guide for the Cisco CRS Router, Release 5.2.x
89
Implementing Multicast Routing on Cisco IOS XR Software
Configuring MVPN MLDP BIDIR
