3 Select File > New > GOQAM > RF GOQAM. The Set Up RF GoQAM window
opens with the Basic Parameters tab to the forefront and displays the Basic
Parameters fields as shown in the following example.
Basic Parameters
The following table lists the Basic Parameters fields and their descriptions.
Field Description
Headend Name Displays the name of the headend with which the modulator
is associated
QAM Name Displays the name used for the modulator
IP Address Displays the IP address of the Ethernet interface through
which the DNCS manages and controls the modulator
Modulation Type Allows you to specify one of the following modulation types
for each of the carriers:
ITU J.83 Annex B (6 MHz)
ITU J.83 Annex C DAVIC/DVB
(6 MHz)
Note: The default value is ITU J.83 Annex B (6 MHz).
