Set Up UpConverter Connectivity
The following table lists the Set Up UpConverter Connectivity field descriptions.
Field Description
UpConverter Name Identifies the name of the selected UpConverter and
allows you to select the Input Port
Headend Name Identifies the headend in which the input device exists
Device Type Identifies the type of input device to which the IF
GoQAM is connected
Device Name Identifies the name of the input device to which the IF
GoQAM is connected
Show TSIDs/IPs Displays the Transport Stream (TS) IDs and Internet
Protocol addresses (IPs)
Show (slot, port) Displays the slot and port of the card connected to the RF
GoQAM
Legend Displays a group of icons that represent network
elements that may be displayed in the graphical drawing
area
