4-20
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 4 Installing a Cisco Nexus 7010 Chassis
Installing the Front Doors and Frame Assembly
Figure 4-13 Attaching the Door Frames to the Chassis
a.
Remove the EMI panel by unscrewing its four captive screws until each is free of the chassis (see
Figure 4-14).
1 For each of two door frames, tighten three
captive screws to secure the frame to the chassis.
