5-26
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 5 Installing a Cisco Nexus 7018 Chassis
Installing the Front Door and Air Intake Frame
Figure 5-17 Fastening Ball-Point Studs to the Air Intake Area
Step 8
Align the air intake frame to the four ball-point studs and press the frame onto the chassis as shown in
Figure 5-18. The captive screws on the air-intake frame should align with their screw holes in the
chassis.
1 Ball-headed stud
