Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 1 Overview
Cisco Nexus 7000 Series
1 Air intake area for power supply units 5 Supervisor modules (1 or 2 modules in slots
1 and 2). These modules are of only one of
the following types (if installing two
supervisor modules, both modules must be
the same type with the same amount of
memory):
• Supervisor 1 (N7K-SUP1)
• Supervisor 2 (N7K-SUP2)
• Supervisor 2 Enhanced (N7K-SUP2E)
2 Fabric modules (up to 5) (N7K-C7009-FAB-2) 6 Cable management top hood with LEDs
3 Cable management side frame 7 Air intake areas for supervisor, I/O, and
fabric modules
4 I/O or NAM modules (1 to 7 modules in slots 3 to 9). These modules
are a combination of the following:
• F1 Series
–
32-port 1- and 10-Gigabit Ethernet I/O modules
(N7K-F132XP-15)
–
48-port 1-/10-GBASE-T with XL option (N7K-F248XT-25E)
• F2 Series
–
48-port 1-/10-Gigabit SFP+ with XL option and FEX support
(N7K-F248XP-25 and N7K-F248XP-25E
1
)
• M1 Series
–
48-port 10/100/1000 I/O modules (N7K-M148GT-11)
–
48-port 10/100/1000 I/O modules with XL option
(N7K-M148GT-11L)
–
48-port 1-Gigabit Ethernet I/O modules (N7K-M148GS-11)
–
48-port 1-Gigabit Ethernet I/O modules with XL option
(N7K-M148GS-11L)
–
32-port 10-Gigabit Ethernet I/O modules with FEX support
(N7K-M132XP-12)
–
32-port 10-Gigabit Ethernet I/O modules with XL option and
FEX support (N7K-M132XP-12L)
–
8-port 10-Gigabit Ethernet I/O modules with XL option
(N7K-M108X2-12L)
• M2 Series
–
24-port 10-Gigabit Ethernet I/O modules with XL option and
FEX support (N7K-M224XP-23L)
–
6-port 40-Gigabit Ethernet I/O modules with XL option
(N7K-M206XP-23L)
–
2-port 100-Gigabit Ethernet I/O modules with XL option
(N7K-M202XP-23L)
Alternatively, one or more of these slots can be used for Network
Analysis Modules (NAMs) (N7K-SM-NAM-K9).
8 Handles used for adjusting placement of
chassis on mechanical lift
