1-8
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 1 Overview
Cisco Nexus 7000 Series
Figure 1-3 Standard Hardware Features on the Rear of a Cisco Nexus 7009 Chassis
1. The Cisco Nexus F2-Series 48-port 1/10-Gigabit SFP+ module supports all of the standard features of F2 modules and it functions like an F2-series
module with Layer 2 and Layer 3 enabled. These modules also support IPv6 DSCP-to-Queue mapping.
1 Fan tray (1) 2 Power supplies (1 or 2)—these modules are a
combination of the following:
• 6 kW AC power supply
(N7K-AC-6.0KW)
• 7.5 kW AC power supply
(N7K-AC-7.5KW-INT [international
plugs])
(N7K-AC-7.5KW-US [US plugs])
• 6 kW DC power supply
(N7K-DC-6.0KW)
• Blank filler plate (installed in place of a
missing power supply to maintain the
designed airflow)
