10-65
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 10 Installing or Replacing Components
Replacing the Front Doors and Frame Assembly on the Cisco Nexus 7010 Chassis
Figure 10-20 Removing the Front Door Assemblies
1 On each door frame, loosen three captive screws
and remove the door frame from the chassis.
