10-66
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 10 Installing or Replacing Components
Replacing the Front Doors and Frame Assembly on the Cisco Nexus 7010 Chassis
Step 3 Remove the bottom frame assembly by completely unscrewing the four M4 x 6 mm screws identified in
Figure 10-21.
Figure 10-21 Removing the Bottom Frame
Step 4
If you are returning the frame components to Cisco, repack them in their original packing materials.
1 Bottom frame 2 Unscrew four M4 x 6 mm screws that hold the bottom frame to the chassis
