10-95
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 10 Installing or Replacing Components
Replacing the Front Door and Air Intake Assemblies on the Cisco Nexus 7018 Chassis
Figure 10-47 Fastening Ball-Point Studs to the Air Intake Area
Step 10
Align the air intake frame to the four ball-point studs and press the frame onto the chassis, as shown in
Figure 10-48. The two captive screws on the air-intake frame should align with their screw holes in the
chassis.
1 Ball-point stud
