A-19
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix A Technical Specifications
Power Supply Cable Specifications
Figure A-9 CAB-C19-CBN Power Cord and Connectors for the 6-kW AC Power Supply Unit
Figure A-10 CAB-ACS-16 Power Cord and Connectors for the 6-kW AC Power Supply Unit
Figure A-11 NEMA L6-30 Power Connector for the 7.5-kW AC Power Supply Unit
Table A-17 7.5 kW AC Power Supply Power Cords
Local
Power Supply Part
Number Cord rating
Power cord reference
illustration
Japan and North America N7K-AC-7.5KW-US 30 A, 250 VAC Figure A-11
International N7K-AC-7.5KW-INT 32 A, 250 VAC Figure A-12
