A-20
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix A Technical Specifications
Power Supply Cable Specifications
Figure A-12 IEC 603090 Power Connector for the 7.5-kW AC Power Supply Unit
Table A-18 3-kW DC Power Supply Power Cord
Locale Part Number Cord Ratings Power Cord Comments
All —
1
45 A 6 AWG
1. Power cords used for the 3-kW DC power supply are supplied by the customer.
Table A-19 6-kW DC Power Supply Power Cord
Locale Part Number Cord Rating Power Cord Reference Illustration
All N7K-DC-CAB 40 A, 48V-48V Figure A-13
