Appendix A Technical Specifications
Chassis Airflow
Figure A-24 Airflow for the Cisco Nexus 7010 Chassis
1 Airflow for cooling the supervisor and I/O
modules
3 Airflow for cooling the power supply units
2 Airflow for cooling the fabric modules
