Appendix E Repacking the Cisco Nexus 7000 Series Switch for Shipment
Repacking the System Components
Figure E-20 Removing One Side of the Front Door
b.
Press the locking button on the back side of the door (behind the opened latch handle) so that the
latch handle flattens to the front side of the door (see Figure E-21).
1 Open the latch handle until it clicks. 2 Swing open the door.
