E-37
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Appendix E Repacking the Cisco Nexus 7000 Series Switch for Shipment
Repacking the System Components
Figure E-21 Location of the Latch Locking Button
c.
Hold the opened side of the door with one hand and use your other hand to open the latch handle on
the hinged side of the door until the handle clicks (see Callout 1 in Figure E-22). Use both hands to
remove the door from the chassis.
1 Locking button for the right latch 2 Locking button for the left latch
