3-30
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
OL-23069-07
Chapter 3 Installing a Cisco Nexus 7009 Chassis
Installing the Front Door and Air Intake Frame
Figure 3-20 Positioning the Hinge Bracket to the Cable Management Frames and Chassis
Step 5
Attach the bracket to the chassis and cable management frames with eight loosely fastened M4x8 screws,
as shown in Figure 3-21.
1 Alignment pins 2 Alignment holes
