Maximum Power Available for 3-kW AC Power Supplies
The maximum power available for operations depends on the input power from your power source, the number
and output capabilities of your power supplies, and the power redundancy mode that you use. The following
table lists the amount of power available for 3-kW AC power supplies depending on power inputs, numbers
of power supplies, and the mode used.
Full Redundancy
Mode
Input Source
Redundancy
Mode
Power Supply
Redundancy
Mode
Combined ModePower SuppliesPower Inputs
———3000 W11 input (220 V)
3000 W3000 W3000 W6000 W2
3000 W3000 W6000 W9000 W3
6000 W6000 W9000 W12000 W4
—
——1450 W11 input (110 V)
1450 W1450 W1450 W2900 W2
1450 W1450 W2900 W4350 W3
2900 W2900 W4350 W5800 W4
Maximum Power Available for 3-kW DC Power Supplies
The maximum power available for operations depends on the input power from your power source, the number
and output capabilities of your power supplies, and the power redundancy mode that you use. The following
table lists the amount of power available for 3-kW DC power supplies depending on power inputs, numbers
of power supplies, and the mode used.
Full Redundancy
Mode
Input Source
Redundancy
Mode
Power Supply
Redundancy
Mode
Combined ModePower SuppliesPower Inputs
———3000 W11 input
3000 W3000 W3000 W6000 W2
3000 W3000 W6000 W9000 W3
6000 W6000 W9000 W12000 W4
Maximum Power Available for 3.5-kW Inputs (AC)
The maximum power available for operations depends on the input power from your power source, the number
and output capabilities of your power supplies, and the power redundancy mode that you use. The following
table lists the amount of power available for 3.5-kW HVAC/HVDC power supplies depending on AC power
inputs, number of power supplies, and the mode used.
Cisco Nexus 7706 Hardware Installation Guide
75OL-31330-01
Managing the Switch
Maximum Power Available for 3-kW AC Power Supplies
