Configuration Commands
wlan
Cisco RV34xx Router CLI Reference Guide 44
4
router06000a>wan show interface
wlan
The wlan command provides wireless network communication over short
distances using radio or infrared signals instead of traditional network cabling. A
WLAN typically extends an existing wired local area network. All the wlan
commands are listed here:
• wlan --i interface {enable/disable}
• wlan --i interface --ssid ssid
• wlan --ssid ssid --mode mode --band band --channel channel --vlan vlan
ID
• wlan --ssid ssid --smode disabled
• wlan --ssid ssid --smode wep --authtype {0|1} --encry {128 | 64} --key1
key1 --key2 key2 --key3 key3 --key4 key4 --txkey {1 | 2 | 3 | 4}
• wlan --ssid ssid --smode {wpa2_personal | wpa_personal_mixed} --encry
{TKIP_AES | AES} --skey shared key --krenew renewal-seconds
• wlan --ssid ssid --smode {wpa2_enterprise | wpa_enterprise_mixed} --
encry {TKIP_AES | AES} --rserver radius-server-IP --rport port --skey
shared-key --krenew renew-seconds
Parameters
interface: (For 2.4G) wl0 | wl0.1 | wl0.2 | wl0.3
(For 5G) wl1 | wl1.1 | wl1.2 | wl1.3
mode: bgn-mixed | bg-mixed | gn-mixed | b-only | g-only | n-only | anac-mixed | nac-
mixed | a-only
band: 20 | 20/40 | 80
channel: 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 (channels for 2.4G, 0 means auto)
0 | 36 | 40 | 44 | 48 | 52 | 56 | 60 | 64 | 100 | 104 | 108 | 112 | 116 | 132 | 136 | 140 | 149 |
153 | 157 | 161 | 165 (channels for 5G)
key1: [0-9A-Z] (if encry is 64, the length of key1 is 10 characters, if encry is 128, the
length of key1 is 26 characters)
