Cisco RV132W Command Line Interface Reference Guide

Introduction
CLI Command Conventions
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router CLI Reference Guide 7
1
STEP 1 Connect the end of the light blue console cable with the RJ-45 connector to the
light blue console port on the router.
STEP 2 Connect the end of the cable with the DB-9 connector to the terminal or PC. If your
terminal or PC has a console port that does not accommodate DB-9 connector,
provide an appropriate adapter for that port.
STEP 3 Connect the AC power cord to the power supply.
STEP 4 Connect the power interface cable to the power connector port on the back of the
router.
CLI Command Conventions
There are certain command entry standards that apply to all commands. The
following table describes the command conventions:
Entering Commands
A CLI command is a series of keywords and arguments. Keywords identify a
command, and arguments specify configuration parameters. For example, in the
command interfaces set
appname , and set are keywords, appname is an
argument that specifies the application name. To enter the commands that require
parameters, enter the required parameters after the command keyword.
[ ] In a command line, square brackets indicate an
optional entry.
{ } In a command line, curly brackets indicate a selection
of compulsory parameters separated with the |
character. One option must be selected.
Italics Italic text indicates a parameter, variable, and
arguments.
Bold Command names and keywords are shown in bold.
Screen Display Fixed-width font indicates CLI prompts, CLI commands
entered, and system messages displayed on the
console.
