Cisco SG500-28P Administration Guide

Cisco 500 Series Stackable Managed Switch Administration Guide 17
Contents
Configuring Global Settings 495
Configuring Out-of-Profile DSCP Mapping 496
Defining Class Mapping 498
QoS Policers 499
Defining Aggregate Policers 500
Configuring a Policy 501
Policy Class Maps 502
Policy Binding 504
Managing QoS Statistics 504
Policer Statistics 505
Viewing Single Policer Statistics 505
Viewing Aggregated Policer Statistics 506
Viewing Queues Statistics 506
Chapter 26: SNMP 510
SNMP Versions and Workflow 510
SNMPv1 and v2 511
SNMPv3 511
SNMP Workflow 511
Supported MIBs 513
Model OIDs 513
SNMP Engine ID 514
Configuring SNMP Views 516
Creating SNMP Groups 517
Managing SNMP Users 519
Defining SNMP Communities 521
Defining Trap Settings 523
Notification Recipients 523
Defining SNMPv1,2 Notification Recipients 524
Defining SNMPv3 Notification Recipients 525
SNMP Notification Filters 527

Cisco SG500-28P Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Flash Memory	32 MB
Operating Humidity	10% to 90% non-condensing
PoE	Yes
Layer	Layer 2 and Layer 3
Stackable	Yes
Power Supply	Internal
Management	Web-based GUI, CLI, SNMP
Jumbo Frame Support	Yes
VLANs	4096 VLANs
MAC Address Table Size	16K entries
Dimensions	440 x 44 x 350 mm
Operating Temperature	0°C to 45°C
Ports	28 (24 x 10/100/1000 PoE+ ports, 4 x 10/100/1000/SFP combo ports)
