Cisco SG500-28P Administration Guide

IP Configuration: RIPv2
Configuring RIP
347 Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3
18
- Enable/disable RIP to advertise static or connected routes and its metric
on the IP interface, using the RIPv2 Properties page.
- Configure the offset added to the metric for incoming routes on an IP
interface, using the RIPv2 Settings page.
- Enable passive mode on an IP interface, using the RIPv2 Settings page.
- Control which routes are processed in the incoming/outgoing routing
updates by specifying an IP address list on the IP interface (see Access
Lists).
- Advertise default route entries on the IP interface, using the RIPv2
Settings page.
- Enable RIP authentication on an IP Interface, using the RIPv2 Settings
page.
RIPv2 Properties
To enable/disable RIP on the device.
STEP 1 Click IP Configuration > RIPv2 > RIPv2 Properties.
STEP 2 Select the following options as required:
• RIP—The following options are available:
- Enable—Enable RIP.
- Disable—Disable RIP. Disabling RIP deletes the RIP configuration on the
system.
- Shutdown—Set the RIP global state to shutdown.
• RIP Advertisement—Select to enable sending routing updates on all RIP IP
interfaces.
• Default Route Advertisement—Select to enable sending the default route
to the RIP domain. This route will serve as the default router.
• Default Metric—Enter the value of the default metric (refer to Redistribution
Feature).

Cisco SG500-28P Specifications

General

Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Flash Memory	32 MB
Operating Humidity	10% to 90% non-condensing
PoE	Yes
Layer	Layer 2 and Layer 3
Stackable	Yes
Power Supply	Internal
Management	Web-based GUI, CLI, SNMP
Jumbo Frame Support	Yes
VLANs	4096 VLANs
MAC Address Table Size	16K entries
Dimensions	440 x 44 x 350 mm
Operating Temperature	0°C to 45°C
Ports	28 (24 x 10/100/1000 PoE+ ports, 4 x 10/100/1000/SFP combo ports)
